Spiral Drilling Rig
Foundation & pile
Spiral (auger) drilling rig for soft-soil and foundation piling works, available in 6 m / 10 m / 12 m configurations.
- Vehicle Size7200x2300x2700 mm
- Drill Depth6 m
- Track Shoe Width400 mm
- Up-down Steering360 deg rotation
- Electrical Machinery22 kW
- Walking Speed2-5 km/h
Technical Specifications
| Parameter | 6 m | 10 m | 12 m |
|---|---|---|---|
| Vehicle Size | 7200x2300x2700 mm | 11000x2300x2800 mm | 11000x2300x2900 mm |
| Drill Depth | 6 m | 10 m | 12 m |
| Track Shoe Width | 400 mm | 400 mm | 400 mm |
| Up-down Steering | 360 deg rotation | 360 deg rotation | 360 deg rotation |
| Electrical Machinery | 22 kW | 22 kW | 22 kW |
| Walking Speed | 2-5 km/h | 2-5 km/h | 2-5 km/h |
| Drilling Diameter | 600 mm | 600 mm | 600 mm |
| Dead-weight | 13 t | 10 t | 14 t |
Specifications can be customized for special requirements. Contact our engineers for drawings and a quotation.
